The Fraunhofer IEE designed a model for estimating the installed base and analyzing the impact and sensitivity of variable technical parameters or changes in policy and regulation. With the model, it is estimated that around 15 million MV switchgear functional units are installed in Europe today of which 10 million are using SF6. This relates to a banked volume of 8600 t SF6 or an equivalent of 196 million tons of C02.
Three main drivers define the development of SF6 emissions in medium voltage switchgear: network extensions, operation emissions, and end-of-life handling. The end-of-life handling has the key role. Network extension effects are also significant. Business as usual would lead to an increase of about 40% of the SF6 banked volume in MV switchgear until 2050.
Considering the European Green Deal and Circular Economy, zero emissions by 2050 is only achievable by forced replacement of switchgear with F-gas free technology. For the replacement high quality end-of-life handling is the key to minimize greenhouse gas emissions. While a well-established end-of-life management is expected for utilities and bigger industries, incentives like credits for controlled decommissioning of SF6 equipment could be considered to reach the fractured private market.
The Grenoble Ecole de Mangement conducted an empirical study to better understand customer-purchasing criteria for medium voltage switchgear, including the interplay of technical, economic as well as environmental aspects. A survey including stated preferences choice experiments (SPCE) was completed anonymously by a total of 443 respondents in five European countries.
Results from the survey suggest that customers for MV switchgear expect a decrease in use of SF6 technology in the near future. This decrease, however, is expected to be primarily driven by policies and regulations, rather than technological change or prices. Customers remain in fact uncertain which technology will most likely replace SF6.
At the same time, respondents express an interest in environmental aspects of different MV switchgear technologies. Eco-friendliness was in fact identified as one of the most important purchase criteria for MV switchgear.
The study was performed between March 2019 and April 2020 focusing on medium voltage (MV) switchgear in electricity grids in the European Union. Participation in the study was open to all electricity grid stakeholders.
Summary and detailed results for both parts of the study are available on the project web site www.f-gas-free.eu.
